BYKG-VIII | Negative pressure hood with LCD display for compound preparation (BYKG-VIII) | 184L internal capacity

Key Features

• Negative pressure environment in work area to protect operator and samples
• Cold-rolled steel construction with anti-bacteria powder coating
• 184L internal capacity
• LCD display
• Active carbon filter
• Acrylic front window (manual opening and closing): 590 mm opening
• Airflow velocity range of 0.3 m/s - 0.8 m/s

Product Description

The BYKG-VIII is a hood designed for the preparation of samples under negative pressure conditions in the working area to protect the operator and the samples from contamination. It is constructed from cold-rolled steel with an anti-bacteria powder coating and has an internal capacity of 184L. It has an LCD display to control the airflow velocity from 0.3 m/s - 0.8 m/s

Excellent visualisation of the working area of the BYKG-VIII is through a manually operated acrylic window. Air filtration is achieved by an active carbon filter.

Specifications

Manufacturer	Biobase
Model number	BYKG-VIII
External size (W x D x H)	600 mm x 580 mm x 1060 mm
Internal size (W x D x H)	580 mm x 520 mm x 610 mm
Internal capacity	184L
Display	LCD
Airflow velocity	≥ 0.3 m/s - 0.8 m/s
Construction material	Main body | Cold-rolled steel with anti-bacteria powder coating Work table | 304 stainless steel
Filter	Active carbon filter
Noise	≤ 60 dB
Front window	Acrylic | Manual opening and closing | UV-resistant
Maximum opening	590 mm
LED lamp	1 x 4W
UV lamp	1 x 8W | Emission: 253.7 nm
Power consumption	150 W
Electrical requirements	220 VAC±10% | 50/60Hz
Standard accessories	Active carbon filter | LED lamp | UV lamp x 2 | Waterproof socket
Optional accessories	Base stand
Gross weight	90 Kg
