099.M1301.00C | Maelstrom 2410 automated nucleic acid extraction system with 24 sample capacity for samples up to 10 mL








Key Features

  • Utilises patented whirl stirring mixing technology which significantly reduces cross-contamination of adjacent wells compared to other mixing technologies
  • Fully automated to avoid human error and to ensure consistent quality
  • Can process up to 24 samples simultaneously
  • Ideal for applications in molecular diagnostics and life sciences
  • Compatible reagent kits available
  • Processing volume of up to 10 mL
  • Spin tips stir magnetic beads at speeds up to 2500 rpm and magnetic induction of >4700 Gauss

Description

The Maelstrom™ 2410 is a powerful high throughput nucleic acid extraction system designed to process up to 24 samples simultaneously. The instrument utilises specialised spin tips and rods with a magnetic induction of >4700 Gauss to efficiently mix and collect magnetic beads to extract nucleic acid from an extensive range of sample types.

The Maelstrom™ 2410 features a novel spin methodology rather than the vertical mixing technology used in other extraction systems. This approach significantly reduces the risk of cross-contamination between adjacent wells.



The Maelstrom™ 2410 can process samples ranging from 100 µL to 10000 µL .  Simple menu navigation and an intuitive user interface allows for easy end-user parameter selection.



More Information

Please click here to view our range of Nucleic Acid Extraction Kits for the Maelstrom™ 2410.

Specifications

Manufacturer
Taiwan Advance Nanotech Inc. (TANBead)
Model number
Maelstrom™ 2410
Samples per run
Up to 24
Processing volume
100 µL to 10000 µL
Magnetic rod
>4700 Gauss
Spin speed
Up to 2500 rpm
Display
180 mm touchscreen
UV
UV-C type:  4 W
HEPA
E10 Class
Heater
4 heating plates
Weight
98 Kg
Dimensions (W x D x H)
890 mm x 575 mm x 775 mm
Power requirements
220 VAC: 50 Hz
