W3012805.01 | Infrared hot plate and magnetic stirrer with ceramic glass top plate, TFT display, PT100 sensor and advanced PID temperature control (WH280-R)

Key Features

• Advanced infrared heating system ensures reliability and temperature stability
• Features self-optimising Intelligent Cascade Control for optimal temperature stability
• Clockwise or counterclockwise rotation
• Easy-to-clean anti-corrosive top plate made of ceramic glass that is resistant to temperature shocks up to 700ºC
• Bright and clear TFT displays instrument operating parameters
• Sealed outer shell and isolated critical parts enhance longevity even in harsh operating conditions
• Drainage system above control board to prevent liquids accessing instrument interior
• External PT100 temperature sensor connection for direct and precise control of the actual temperature (PT100 sensor included with purchase) and a second thermocouple sensor for use as a reference
• Sensor in medium alarm to notify end-user of sensor failure during heating
• High temperature indicator for operator safety
• Set of 2 PID temperature controls for oil and water

Description

This advanced infrared hot plate and magnetic stirrer from Wiggens features an easy-to-clean anti-corrosive top plate made of ceramic glass and a bright, clear TFT that displays temperature, stirring speed, time and safety temperature. The WH280-R can rotate in a clockwise or counterclockwise rotation and features self-optimising Intelligent Cascade Control for optimal temperature stability.

The WH280-R has a sealed outer shell and isolated critical parts to enhance longevity even in harsh operating conditions and a drainage system above the control board to prevent liquids accessing the instrument's interior.

The WH280-R has a connection for a PT100 temperature sensor (included with the instrument purchase) to allow for external temperature control. A high temperature indicator enhances operator safety during operation and a sensor in medium alarm notifies the end-user of sensor failure during heating.

More Information

The following items are included with the purchase of the WH280-R:

Part Number	Product Description
W3012805	WH280-R magnetic stirrer with round ceramic glass hot plate
PT100-01	PT100 temperature sensor (Type 1) Length: 170 mm Diameter: 4 mm Material: Stainless steel Operating range: -30 to +300°C
PT100-05	Holder and clamp for PT100 temperature sensor

Optional Accessories

Part Number	Product Description
PT100-02	PT100 temperature sensor, Type II Length: 300 mm Diameter: 4 mm Material: Stainless steel Operating range: -30 to ~+300°C
PT100-03	PT100 temperature sensor, Type III Length: 170 mm Diameter: 4 mm Material: Stainless steel, PTFE-coated Operating range: -30 to ~+250°C
PT100-04	PT100 temperature sensor, Type IV Length: 300 mm Diameter: 4 mm Material: Stainless steel, PTFE coated Operating range: -30 to ~+250°C
PT100-06	PT100 temperature Sensor, Type VI Length: 250 mm Diameter: 4 mm Material: Glass Temperature range: -30ºC ~+300°C

Specifications

Manufacturer	Wiggens
Model number	WH280-R
Display mode	TFT
Top plate material	Ceramic glass
Maximum hot plate temperature	450ºC
Maximum solvent temperature  (thermocouple  sensor)	300ºC
Temperature stability (thermocouple sensor)	±2ºC
Safety temperature	50ºC - 500ºC adjustable
High temperature protection	10ºC - 50ºC adjustable
Stirring speed range	100 rpm - 1500 rpm
Direction of rotation	Clockwise or counterclockwise
Heating capacity	800 W
Maximum stirring capacity (water)	20 L
External temperature sample for sample	PT100
External reference temperature sensor	Thermocouple
Timer	1 minute - 1999 minutes or continuous
PID parameters	2 sets (oil and water)
Interfaces	USB | RS232 | RS485
Top plate diameter	135 mm
Instrument dimensions (W x D x H)	190 mm x 320 mm x 90 mm
Weight	3 Kg
Power requirements	220 VAC: 50 Hz
